| Type | RQM-8500 |
| Production range | φ0.7-φ3.5mm |
| No. of line | 18 - 38 |
| No. Of passes perline | 6 - 12 |
| Wire pitch | 12 - 13.5mm |
| Speed | 6 - 50 m/min |
| Self-bonding oven | Hot air circulation and exchange type |
| Length of the oven | 8500 mm |
| Length of softening oven | 13000 - 15300 mm |
| Suitable pay off spool | φ400-φ630,roll payoff |
| Take up method | Torque type axes winding unit |
| Suitable take-up spool | PT25-PT60/PT25-PT270 |
| Namel application method | Felt/Die |
| Application method | Automatic liquid level adjustment paint box |
| Exhaust gas dispose | Two catalysts burning system |
| Installed electric power | 300 - 430 KW |
|
Specs （mm） |
| φ0.8 |
| φ1.0 |
| φ1.2 |
| φ1.5 |
| DV | Production speed(m/min) | Daily output(kg/24h) |
Daily power consumption Kwh/24h (felt painting) |
|||
| PE | PU | PE | PU | PE | PU | |
| 27-32 | 30-35 | 33.8-80 | 37.5-43.8 | 6912-8192 | 7680 |
Production PE DV27 φ 1.0 mm copper wire About 900 degrees |
| 27-31 | 30-34 | 27-31 | 30-34 | 8640-9920 | 9600 | |
| 27-30 | 30-33 | 22.5-25 | 25-27.5 | 10368 | 11520 | |
| 27-29 | 30-32 | 18-19.3 | 20-21.3 | 12960 | 14400 | |
|
Specs （mm） |
| Φ2.0 |
| Φ2.5 |
| DV | Production speed(m/min) | Daily output(kg/24h) |
Daily power consumption Kwh/24h (felt painting) |
|||
| PE | PU | PE | PU | PE | PU | |
| 26-28 | 28-31 | 13-14 | 14-15.5 | 14560-15680 | 15680-17360 |
Production PE DV27 Φ About 1300 degrees for 2.0 mm copper wire |
| 25-27 | 27-30 | 10-10.8 | 10.8-12 | 17500-18900 | 18900-21000 | |
